BLE 4.2 Single Mode Module

BLE 4.2 SINGLE MODE MODULE

8051 8 bit Processor

128K Flash, 8KB SRAM

Included 32.768kHz and 16Mhz Crystal

RX Sensitivity: -92dBm TX Output: +6dBm

Low Power Consumption: TX 18mA RX 18.5mA

Supply Voltage: 2.0-3.6V

Operation Temperature Range from -40 to 85 Degree

PCB Antenna Design

Compact Size: 12.7Lx8.4Wx2Hmm

Interfaces: UART, SPI, i2C, GPIO, 12 bit 6 Channel SAR ADC, PWMx4, Temperature Sensor

BLE Stack, Profile Intergrate

Application: Mouse, Keyboard, HID, Remote Control, Anti Loss, Pet Finder, X'mas LED Lighting, Selfie

FCC/CE/IC APPROVAL, REACH/ROHS COMPLIANT
